PONTOS SQUARE

Colours

White
Black

Order now Request consultation

Credit: shutterstock

From the same product family

PONTOS ROUND

12 Items found Filter (0)

PONTOS SQUARE Black

Item no.

Colour of body

Beam angle

Colour temperature

Luminous flux

Item no. 305-624824b40k

Colour of body black

Beam angle 24°

Colour temperature 4000K

Luminous flux 1310 lm

Credit: shutterstock

Specifications

Light source	LED 13W
Luminous flux	1310 lm
Current sec.	350 mA
Colour temperature	4000K
CRI	>80
Converter	without converter
Dimmability	see converter
Light emission area	direct
Beam angle	24°
Voltage	36 VDC
Length	89 mm
Width	89 mm
Height	80 mm
Ceiling cutout	78x78 mm
Mounting depth	110 mm
IP protection class	IP44/IP20
IP protection class	protection cl. III
Material	aluminium
Colour of body	black
RAL	9005
Lifetime	L80 B10 50 000 h
Energy efficiency class	E

Downloads

Availability & Price

RRP excl. VAT
€ 74,00

Order accessories Request consultation

Payment by invoice

Reliable delivery

Premium service

Top quality

Item no. 305-624836b40k

Colour of body black

Beam angle 36°

Colour temperature 4000K

Luminous flux 1310 lm

Credit: shutterstock

Specifications

Light source	LED 13W
Luminous flux	1310 lm
Current sec.	350 mA
Colour temperature	4000K
CRI	>80
Converter	without converter
Dimmability	see converter
Light emission area	direct
Beam angle	36°
Voltage	36 VDC
Length	89 mm
Width	89 mm
Height	80 mm
Ceiling cutout	78x78 mm
Mounting depth	110 mm
IP protection class	IP44/IP20
IP protection class	protection cl. III
Material	aluminium
Colour of body	black
RAL	9005
Lifetime	L80 B10 50 000 h
Energy efficiency class	E

Downloads

Availability & Price

RRP excl. VAT
€ 74,00

Order accessories Request consultation

Payment by invoice

Reliable delivery

Premium service

Top quality

Item no. 305-624836b27k

Colour of body black

Beam angle 36°

Colour temperature 2700K

Luminous flux 1250 lm

Credit: shutterstock

Specifications

Light source	LED 13W
Luminous flux	1250 lm
Current sec.	350 mA
Colour temperature	2700K
CRI	>80
Converter	without converter
Dimmability	see converter
Light emission area	direct
Beam angle	36°
Voltage	36 VDC
Length	89 mm
Width	89 mm
Height	80 mm
Ceiling cutout	78x78 mm
Mounting depth	110 mm
IP protection class	IP44/IP20
IP protection class	protection cl. III
Material	aluminium
Colour of body	black
RAL	9005
Lifetime	L80 B10 50 000 h
Energy efficiency class	E

Downloads

Availability & Price

RRP excl. VAT
€ 74,00

Order accessories Request consultation

Payment by invoice

Reliable delivery

Premium service

Top quality

Item no. 305-624824b

Colour of body black

Beam angle 24°

Colour temperature 3000K

Luminous flux 1310 lm

Credit: shutterstock

Specifications

Light source	LED 13W
Luminous flux	1310 lm
Current sec.	350 mA
Colour temperature	3000K
CRI	>80
Converter	without converter
Dimmability	see converter
Light emission area	direct
Beam angle	24°
Voltage	36 VDC
Length	89 mm
Width	89 mm
Height	80 mm
Ceiling cutout	78x78 mm
Mounting depth	110 mm
IP protection class	IP44/IP20
IP protection class	protection cl. III
Material	aluminium
Colour of body	black
RAL	9005
Lifetime	L80 B10 50 000 h
Energy efficiency class	E

Downloads

Availability & Price

RRP excl. VAT
€ 74,00

Order accessories Request consultation

Payment by invoice

Reliable delivery

Premium service

Top quality

Item no. 305-624824b27k

Colour of body black

Beam angle 24°

Colour temperature 2700K

Luminous flux 1250 lm

Credit: shutterstock

Specifications

Light source	LED 13W
Luminous flux	1250 lm
Current sec.	350 mA
Colour temperature	2700K
CRI	>80
Converter	without converter
Dimmability	see converter
Light emission area	direct
Beam angle	24°
Voltage	36 VDC
Length	89 mm
Width	89 mm
Height	80 mm
Ceiling cutout	78x78 mm
Mounting depth	110 mm
IP protection class	IP44/IP20
IP protection class	protection cl. III
Material	aluminium
Colour of body	black
RAL	9005
Lifetime	L80 B10 50 000 h
Energy efficiency class	E

Downloads

Availability & Price

RRP excl. VAT
€ 74,00

Order accessories Request consultation

Payment by invoice

Reliable delivery

Premium service

Top quality

Item no. 305-624836b

Colour of body black

Beam angle 36°

Colour temperature 3000K

Luminous flux 1310 lm

Credit: shutterstock

Specifications

Light source	LED 13W
Luminous flux	1310 lm
Current sec.	350 mA
Colour temperature	3000K
CRI	>80
Converter	without converter
Dimmability	see converter
Light emission area	direct
Beam angle	36°
Voltage	36 VDC
Length	89 mm
Width	89 mm
Height	80 mm
Ceiling cutout	78x78 mm
Mounting depth	110 mm
IP protection class	IP44/IP20
IP protection class	protection cl. III
Material	aluminium
Colour of body	black
RAL	9005
Lifetime	L80 B10 50 000 h
Energy efficiency class	E

Downloads

Availability & Price

RRP excl. VAT
€ 74,00

Order accessories Request consultation

Payment by invoice

Reliable delivery

Premium service

Top quality

PONTOS SQUARE White

Item no.

Colour of body

Beam angle

Colour temperature

Luminous flux

Item no. 305-624836w40k

Colour of body white

Beam angle 36°

Colour temperature 4000K

Luminous flux 1310 lm

Credit: shutterstock

Specifications

Light source	LED 13W
Luminous flux	1310 lm
Current sec.	350 mA
Colour temperature	4000K
CRI	>80
Converter	without converter
Dimmability	see converter
Light emission area	direct
Beam angle	36°
Voltage	36 VDC
Length	89 mm
Width	89 mm
Height	80 mm
Ceiling cutout	78x78 mm
Mounting depth	110 mm
IP protection class	IP44/IP20
IP protection class	protection cl. III
Material	aluminium
Colour of body	white
RAL	9003
Lifetime	L80 B10 50 000 h
Energy efficiency class	E

Downloads

Availability & Price

RRP excl. VAT
€ 74,00

Order accessories Request consultation

Payment by invoice

Reliable delivery

Premium service

Top quality

Item no. 305-624836w

Colour of body white

Beam angle 36°

Colour temperature 3000K

Luminous flux 1310 lm

Credit: shutterstock

Specifications

Light source	LED 13W
Luminous flux	1310 lm
Current sec.	350 mA
Colour temperature	3000K
CRI	>80
Converter	without converter
Dimmability	see converter
Light emission area	direct
Beam angle	36°
Voltage	36 VDC
Length	89 mm
Width	89 mm
Height	80 mm
Ceiling cutout	78x78 mm
Mounting depth	110 mm
IP protection class	IP44/IP20
IP protection class	protection cl. III
Material	aluminium
Colour of body	white
RAL	9003
Lifetime	L80 B10 50 000 h
Energy efficiency class	E

Downloads

Availability & Price

RRP excl. VAT
€ 74,00

Order accessories Request consultation

Payment by invoice

Reliable delivery

Premium service

Top quality

Item no. 305-624836w27k

Colour of body white

Beam angle 36°

Colour temperature 2700K

Luminous flux 1250 lm

Credit: shutterstock

Specifications

Light source	LED 13W
Luminous flux	1250 lm
Current sec.	350 mA
Colour temperature	2700K
CRI	>80
Converter	without converter
Dimmability	see converter
Light emission area	direct
Beam angle	36°
Voltage	36 VDC
Length	89 mm
Width	89 mm
Height	80 mm
Ceiling cutout	78x78 mm
Mounting depth	110 mm
IP protection class	IP44/IP20
IP protection class	protection cl. III
Material	aluminium
Colour of body	white
RAL	9003
Lifetime	L80 B10 50 000 h
Energy efficiency class	E

Downloads

Availability & Price

RRP excl. VAT
€ 74,00

Order accessories Request consultation

Payment by invoice

Reliable delivery

Premium service

Top quality

Item no. 305-624824w

Colour of body white

Beam angle 24°

Colour temperature 3000K

Luminous flux 1310 lm

Credit: shutterstock

Specifications

Light source	LED 13W
Luminous flux	1310 lm
Current sec.	350 mA
Colour temperature	3000K
CRI	>80
Converter	without converter
Dimmability	see converter
Light emission area	direct
Beam angle	24°
Voltage	36 VDC
Length	89 mm
Width	89 mm
Height	80 mm
Ceiling cutout	78x78 mm
Mounting depth	110 mm
IP protection class	IP44/IP20
IP protection class	protection cl. III
Material	aluminium
Colour of body	white
RAL	9003
Lifetime	L80 B10 50 000 h
Energy efficiency class	E

Downloads

Availability & Price

RRP excl. VAT
€ 74,00

Order accessories Request consultation

Payment by invoice

Reliable delivery

Premium service

Top quality

Item no. 305-624824w27k

Colour of body white

Beam angle 24°

Colour temperature 2700K

Luminous flux 1250 lm

Credit: shutterstock

Specifications

Light source	LED 13W
Luminous flux	1250 lm
Current sec.	350 mA
Colour temperature	2700K
CRI	>80
Converter	without converter
Dimmability	see converter
Light emission area	direct
Beam angle	24°
Voltage	36 VDC
Length	89 mm
Width	89 mm
Height	80 mm
Ceiling cutout	78x78 mm
Mounting depth	110 mm
IP protection class	IP44/IP20
IP protection class	protection cl. III
Material	aluminium
Colour of body	white
RAL	9003
Lifetime	L80 B10 50 000 h
Energy efficiency class	E

Downloads

Availability & Price

RRP excl. VAT
€ 74,00

Order accessories Request consultation

Payment by invoice

Reliable delivery

Premium service

Top quality

Item no. 305-624824w40k

Colour of body white

Beam angle 24°

Colour temperature 4000K

Luminous flux 1310 lm

Credit: shutterstock

Specifications

Light source	LED 13W
Luminous flux	1310 lm
Current sec.	350 mA
Colour temperature	4000K
CRI	>80
Converter	without converter
Dimmability	see converter
Light emission area	direct
Beam angle	24°
Voltage	36 VDC
Length	89 mm
Width	89 mm
Height	80 mm
Ceiling cutout	78x78 mm
Mounting depth	110 mm
IP protection class	IP44/IP20
IP protection class	protection cl. III
Material	aluminium
Colour of body	white
RAL	9003
Lifetime	L80 B10 50 000 h
Energy efficiency class	E

Downloads

Availability & Price

RRP excl. VAT
€ 74,00

Order accessories Request consultation

Payment by invoice

Reliable delivery

Premium service

Top quality
